Feed Mixers

Jaylor 6850

Jaylor’s Twin Auger mixers are engineered for farms that need fast, consistent feed processing with maximum efficiency. Featuring Jaylor’s patented square-cut auger design, these mixers deliver a uniform, fluffy TMR while reducing fuel use and mixing time. The twin-auger layout handles larger volumes with ease, improves vertical feed movement, and ensures even blending of all ingredients, from long fibre to finer supplements. Built tough and simple to maintain, Jaylor Twin Augers are a reliable choice for New Zealand operations looking for performance, durability, and low total cost of ownership.

6 Models

Jaylor 6425

Jaylor 6750

Jaylor 6750HD

Jaylor 6850

Jaylor 6850AT

Jaylor 6850HD

Capacity No Extension

22.7m3

Capacity 12" extension

25.8m3

Capacity 16" extension

27.2m3

Weight

6100kg

Length

782cm

Height

274cm

Jaylor 6850

Overview
Features
Models
Video
Gallery

The Jaylor 6850 delivers increased capacity thanks to its larger, heavy-duty steel bowl. With 16-inch extensions, total capacity can be boosted to an impressive 26 m³.

Like all Jaylor twin-auger mixers, it remains extremely manoeuvrable due to the axle being positioned just behind the centre of the loaded bowl. This design dramatically reduces downward pressure on the tractor drawbar and provides exceptional turning ability in tight areas.

The 6850 is also the first model in the lineup that can be ordered in a Heavy Duty (HD) configuration. The HD option includes a walking-beam axle and upgraded ¾-inch auger flighting for increased durability and performance in demanding conditions.

Optional All Terrain Tyres

Jaylor’s new All-Terrain mixers go where other mixers can’t. With massive flotation tires and extra clearance, the new All-Terrain mixers handle mud, snow, and rugged pastures no problem.

Contact your local dealership to find out if the Jaylor 6425AT will suit your farm.

Contact your local dealer here

Save time while using 20% less horsepower

Using 20% less horsepower and requiring less time per mix than conventional mixers — a Jaylor mixer reduces fuel consumption and ensures a longer operating life.

The Jaylor Auger

Sloped Top

Exclusive, patented design, prevents bale bridging, enabling rapid cutting and efficient mixing of even the toughest forages, enhancing overall feed quality.

Vertical Knives

Enhances cutting efficiency, reducing forage processing times and improving the distribution of high forage rations to ensure a cleaner, more uniform mix.

Slide Plate Technology

Gathers feed gently into the auger, reducing friction and cutting horsepower needs by 20%, which means lower energy costs and a smoother operation.

Square-Cut Edges

Patented design to reduce pressure on the mix, rapidly and efficiently process baled forage into a uniform TMR, that resists sorting and delivers consistent shaker box results.

Carbide-Coated Knives

Knives that stay sharp longer, thanks to their self-sharpening design. The low angle and serrated edges provide a true slicing action, reducing the need for brute force.

Specifications

Compare specifications below, to find out what will be suit your operations

Models	Jaylor 6425	Jaylor 6750	Jaylor 6750HD	Jaylor 6850	Jaylor 6850AT	Jaylor 6850HD
Augers	1	2			2
Horse Power	70	115	125			135
Capacity No Extension	12.7m3	N/A		22.7m3
Capacity 8" EXTENSION	13.7m3	N/A
Capacity 12" extension	14.6m3	21.0m3		25.8m3
Capacity 16" extension	15.3m3	22.1m3		27.2m3
Weight	3400kg	5900kg		6100kg		8000kg
Length	538cm	737cm		782cm
Height	274cm	284cm	305cm	274cm	310cm	305cm
Drum Width	246cm	231cm		246cm
PTO Speed	540 RPM	1000 RPM
Auger Speed	41 RPM	38 RPM
Knives	9	18
Max. Discharge Height	190cm		201cm	190cm	215cm	203cm
Conveyor Width	91cm
Door Opening Width	107cm
Floor Thickness	16mm					19mm
Drum Wall Thickness	6mm		9mm *with included lower wall stainless steel liner	6mm		9mm *with included lower wall stainless steel liner
Standard Tyre	15.0/55" x 17" 26 ply tyres(2)	15.0/55-17 26 Ply tyres (4)	435/50R-19.5 Super Single tyres (4)	15.0/55-17 26 Ply tyres (4)	710/40R 22.5 FL630 tyres (2)	560/45R 22.5 BKT FL630 tyres (4)
Wheel Assembly	Single Straight Axle	Dual Oscillating	Walking Beam	Dual Oscillating		Walking Beam
