Grass Machinery
McHale R5
The McHale R5 is designed specifically for handling bales efficiently and reliably. Its advanced technology ensures optimal performance across various applications, making it a valuable asset for any farming operation. The R5 features robust construction and innovative engineering that meets the demands of modern agricultural practices.
1 Model
R5
1100KG lift capacity
Weighs 160KG
Can lock one arm in a fixed position
The McHale R5 round bale handler is ideal for collecting round bales, which have been tipped on their ends in the field.
The McHale R5 Round Bale Handler can also be used to collect round bales, which have been left normally after a baler and rotate them through 90 degrees and stack them on their ends so that they hold their shape better.
Specifications
| Models | R5 |
|---|---|
| Hydraulic Requirements | One Double Acting Service |
| Min. Hydraulic Press. | 150 BAR |
| Weight | 160kg |
| Length | 1.42 m |
| Height | 0.59 m |
| Width | 1.75 m (fully open) |
| Lifting Capacity | 1100kg |
| Distance Between Arms | 1.65 m (open) 0.67 (closed) |
