Kverneland PG

The stepless Vari-width® system allows infinite adjustment of working width, available with hydraulic or mechanical furrow settings.

Benefits include easy variation of ploughing capacity to match tractor, implement, and soil conditions. It saves time with up to 30% higher capacity and reduces fuel consumption by up to 18%. The system allows ploughing close to hedges, fences, trees, and ditches.

A unique non-wearing linkage joint between beams and mainframe ensures minimum wear. The correct parallel linkage along the plough maintains a perfect line of pull, reducing draft requirements and wear while delivering consistent, efficient, and high-quality ploughing performance in all conditions.

The plough frame is critical to overall strength. Kverneland frames are heat treated twice by induction, carefully controlling temperature to triple steel strength. This provides exceptional durability, robustness, and flexibility without adding weight.

A stronger frame with less steel reduces pulling forces, wear, lifting effort, tractor strain, and fuel consumption compared to heavier competitor frames.

Welds are eliminated by supplying frames as one solid part, further enhancing longevity.

With over 140 years of experience, Kverneland steels deliver exceptional strength and the best robustness-to-weight ratio on the market. Competitors would need more steel to achieve similar strength, adding weight, increasing wear, and reducing ploughing performance.

Lighter Kverneland steel means easier pulling, lower fuel use, reduced lift requirements, less tractor stress, and more economical operation. Higher resistance provides minimal breakage, less maintenance, longer life, and higher second-hand value.

Kverneland ploughs are designed for reliability when it matters most, giving consistent results in tough conditions, saving time and money, and providing complete peace of mind for the user.

Unbeatable in Stony Conditions

Kverneland’s fully automatic Auto-Reset System ensures trouble-free ploughing in stony soils. A multi-leaf spring system allows plough bodies to release smoothly over obstacles and return automatically to the correct depth.

Different leaf spring packages adapt to soil type: standard 5-leaf springs for soft soils, Heavy Duty 7-leaf springs for most conditions, and double-leaf for very hard or stony ground. Extra heat-treated leaves increase resistance up to 1400 kp and are fitted with a single central bolt.

Each plough body releases independently, minimizing wear, protecting the frame and parts, saving maintenance, and maintaining high second-hand value.
